Page #389 background imageLoading...
Page #389 background image
26-28
by the DHCP server until the conflicting records are deleted.
Example:
Disable logging for DHCP server.
Switch(config)#no ip dhcp conflict logging
Related Command:
clear ip dhcp conflict
26.1.15 ip dhcp excluded-address
Command:
ip dhcp excluded-address <low-address> [<high-address>]
no ip dhcp excluded-address <low-address> [<high-address>]
Function:
Specifies addresses excluding from dynamic assignment; theno ip dhcp excluded-address
<low-address> [<high-address>]” command cancels the setting.
Parameters:
<low-address> is the starting IP address,
[<high-address>] is the ending IP address.
Default:
Only individual address is excluded by default.
Command mode:
Global Mode
Usage Guide:
This command can be used to exclude one or several consecutive addresses in the pool from being
assigned dynamically so that those addresses can be used by the administrator for other purposes.
Example:
Reserving addresses from 10.1.128.1 to 10.1.128.10 from dynamic assignment.
Switch(config)#ip dhcp excluded-address 10.1.128.1 10.1.128.10
26.1.16 ip dhcp pool
Command:
ip dhcp pool <name>
no ip dhcp pool <name>
Function:
Configures a DHCP address pool and enter the pool mode; the “no ip dhcp pool
