Planet SGS-6341-24T4X User Manual

8-4
both: Configure the LLDP function as being able to both send and receive messages.
disable: Configure the LLDP function as not being able to send or receive messages.
Default:
The operating state of the port is “both”.
Command Mode:
Port Configuration Mode.
Usage Guide:
Choose the operating state of the lldp Agent on the port.
Example:
Configure the state of port ethernet 1/0/5 of the switch as “receive”.
Switch(config)#in ethernet 1/0/5
Switch(Config-if-Ethernet 1/0/5)#lldp mode receive
8.7 lldp msgTxHold
Command:
lldp msgTxHold <value>
no lldp msgTxHold
Function:
Set the multiplier value of the aging time carried by update messages sent by the all ports with
LLDP function enabled, the value ranges from 2 to 10.
Parameters:
<value> is the aging time multiplier, ranging from 2 to 10.
Default:
the value of the multiplier is 4 by default.
Command Mode:
Global Mode.
Usage Guide:
After configuring the multiplier, the aging time is defined as the product of the multiplier and the
interval of sending messages, and its maximum value is 65535 seconds.
Example:
Set the value of the aging time multiplier as 6.
Switch(config)#lldp msgTxHold 6

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
