SGS-6341 Series Command Guide
1-69
1.2.2 authentication ipv6 access-class
Command:
authentication ipv6 access-class {<num-std>|<name>}
no authentication ipv6 access-class
Function:
Binding standard IPv6 ACL protocol to login with Telnet/SSH/Web; the no form command will cancel the binding ACL.
Parameters:
<num-std> is the access-class number for standard numeric ACL, ranging between 500-599;
<name> is the access-class name for standard ACL, the character string length is ranging between 1-32.
Default:
The binding ACL to Telnet/SSH/Web function is closed by default.
Command Mode:
Global Mode.
Example:
Binding standard IP ACL protocol to access-class 500.
Switch(config)#authentication ipv6 access-class 500
1.2.3 authentication line login
Command:
authentication line {console | vty | web} login {local | radius | tacacs}
no authentication line {console | vty | web} login
Function:
Configure VTY (login with Telnet and SSH), Web and Console, so as to select the priority of the authentication mode
for the login user. The no form command restores the default authentication mode.
Default:
No configuration is enabled for the console login method by default. Local authentication is enabled for the VTY and
Web login method by default.
Command Mode:
Global Mode.
Usage Guide:
The authentication method for Console, VTY and Web login can be configured respectively. And authentication
method can be any one or combination of Local, RADIUS or TACACS. When login method is configuration in
combination, the preference goes from left to right. If the users have passed the authentication method,
authentication method of lower preferences will be ignored. To be mentioned, if the user receives correspond
protocol’s answer whether refuse or incept, it will not attempt the next authentication method (Exception: if the local
authentication method failed, it will attempt the next authentication method); it will attempt the next authentication

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
