Page #94 background imageLoading...
Page #94 background image
SGS-6341 Series Command Guide
1-94
1.4.19 snmp-server securityip
Command:
snmp-server securityip {enable | disable}
Function:
Enable/disable the safety IP address authentication on NMS manage station.
Command Mode:
Global Mode
Default:
Enable the safety IP address authentication function.
Example:
Disable the safety IP address authentication function.
Switch(config)#snmp-server securityip disable
1.4.20 snmp-server trap-source
Command:
snmp-server trap-source {<ipv4-address> | <ipv6-address>}
no snmp-server trap-source {<ipv4-address> | <ipv6-address>}
Function:
Set the source IPv4 or IPv6 address which is used to send trap packet, the no command deletes the configuration.
Command Mode:
Global Mode
Parameter:
<ipv4-address>: IPv4 address is used to send trap packet in dotted decimal notation
<ipv6-address>: IPv6 address is used to send trap packet in colon hexadecimal.
Usage Guide:
If there is no configuration, select the source address according to the interface address sent by actual trap packet,
when configure the IP address, adopt the configured source address as the source address of trap packet.
Example:
Set the IP address which is used to send trap packet.
Switch(config)# snmp-server trap-source 1.1.1.5
Delete the configured source address which is used to send IPv6 trap packet.
Switch(config)# no snmp-server trap-source 2001::1
