Page #66 background image
SGS-6341 Series Command Guide
1-66
“more”.
Command mode:
Admin and Configuration Mode.
Usage Guide:
This command is used to collect the relative information when the switch operation is malfunctioned.
Example:
Switch#show tech-support
1.1.35 show version
Command:
show version
Function:
Display the version information of the switch.
Command mode:
Admin and Configuration Mode.
Usage Guide:
this command is used to show the version information of the switch, including the hardware version and the software
version information.
Example:
Switch#show version
1.1.36 username
Command:
username <username> [privilege <privilege>] [password <0|7> <password>]
no username <username>
Function:
Configure local login username and password along with its privilege level.
Parameter:
<username> is the name of the user.
<privilege> is the maximum privilege level of the commands that the user is able to execute, its value is limited
between 1 and 15, and 1 by default.
<password> is the password for the user. If input option 7 on password setting, the password is encrypted; if input
option 0, the password is not processed.
Command Mode:
Global Mode.

Table of Contents

Other manuals for Planet SGS-6341-24T4X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet SGS-6341-24T4X and is the answer not in the manual?

Planet SGS-6341-24T4X Specifications

General IconGeneral
Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Form factor1U
CertificationFCC Part 15 Class A, CE
Product colorBlack
Console portRJ-45
SFP+ module slots quantity4
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity24
Routing entries128
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresStacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Flash memory16 MB
Internal memory512 MB
Processor frequency400 MHz
AuthenticationMAC-based authentication, Port-based authentication
Security algorithmsSNMPv3, SSH, SSL/TLS
Throughput95.24 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply included-
Power consumption (max)19.9 W
Heat dissipation67.91 BTU/h
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 90 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width440 mm
Height43.6 mm
Weight3170 g
