Planet SGS-6341-24T4X User Manual

11-44
11.28 show ethernet-oam link-events configuration
Command:
show ethernet-oam link-events configuration [interface {ethernet | } <IFNAME>]
Function:
Show configuration of link events on specified or all ports with OAM enabled, including detection
period and threshold of the events and so on.
Parameter:
<IFNAME>, the port that the statistic information of OAM link events needs to be shown, the statistic
information of OAM link events for all ports will be shown if this parameter is not specified.
Command Mode:
Admin mode
Example:
Show configuration of link events on ethernet 1/0/1.
Switch#show ethernet-oam link-events configuration interface ethernet 1/0/1
Ethernet 1/0/1 link-monitor configuration：
event high-threshold low-threshold window(s)
----------------------------------------------------------------------------------------------------
Err-symbol-Period none 1 2
Err-frame-Period none 1 10
Err-frame none 2 5
Err-frame-second-summary none 2 600
----------------------------------------------------------------------------------------------------
Field
Description
Event
Event type
Err-symbol-Period
Errored symbol event
Err-frame-Period
Errored frame period event
Err-frame
Errored frame event
Err-frame-second-summary
Errored frame seconds event
high-threshold
High threshold
low-threshold
Low threshold
window(s)
Detection period in seconds.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
