Planet SGS-6341-24T4X User Manual

27-50
should be the address of another DHCPv6 relay or the address DHCPv6 server. At most three relay
addresses can be configured for an interface. To be mentioned, the DHCPv6 relay stops working
only if all the relay destination address configurations have been removed. This command is
mutually exclusive to “ipv6 dhcp server” and “ipv6 dhcp client pd” commands.
Example:
Switch(Config-if-Vlan1)#ipv6 dhcp relay destination 2001:da8::1
27.16 ipv6 dhcp server
Command:
ipv6 dhcp server <poolname> [preference <value>] [rapid-commit] [allow-hint]
no ipv6 dhcp server <poolname>
Function:
This command configures the address pool which will be allocated by the DHCPv6 server through
the specified interface. The no form of this command will remove the address pool configuration.
Parameters:
<poolname> is a string with its length less than 32, which designates the name of the address pool
which is associated with the specified interface. If the rapid-commit option has been specified, the
DHCPv6 server send a REPLY packet to the client immediately after receiving the SOLICIT packet.
If the preference option has been specified, <value> will be the priority of the DHCPv6 server, with
its value allowed between 0 and 255, and with 0 by default, the bigger the preference value is, the
higher the priority of the DHCPv6 server. If the allow-hint option has been specified, the client
expected value of parameters will be appended in its request packets.
Command Mode:
Interface Configuration Mode.
Default:
DHCPv6 address pool based on port is not configured by default.
Usage Guide:
This command configure the DHCPv6 address pool which is applied by the DHCPv6 server for the
specified interface, as well as optional parameters. One port only can configure the one DHCPv6
address pool.
Example:
Switch(Config-if-Vlan1)#ipv6 dhcp server PoolA preference 80 rapid-commit allow-hint

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
