Planet SGS-6341-24T4X User Manual

47-27
access-list 3100 deny any-source-mac any-destination-mac udp any-source s-
port 100
any-destination d-port 40000
Displayed information
Explanation
access-list 10(used 1 time(s))
Number ACL10, 0 time to be used
access-list 10 deny any-source
Deny any IP packets to pass
access-list 100(used 1 time(s))
Nnumber ACL10, 1 time to be used
access-list 100 deny ip any-source
any-destination
Deny IP pac
ket of any source IP address and
destination address to pass
access-list 100 deny tcp any-source
any-destination
Deny
TCP packet of any source IP address and
destination address to pass
access-list 1100 permit any-source-mac
any-destination-mac tagged-eth2 14 2 0800
Permit tagged-eth2 with
any source MAC
addresses and any destination MAC addresses
and the packets whose 15th and 16th byte is
respectively 0x08 , 0x0 to pass
access-list 3100 permit any-source-mac
any-destination-mac udp any-source s-port
100 any-destination d-port 40000
Deny the passage of UDP packets with any
source MAC address and destination MAC
address, any source IP address and destination
IP address, and source port 100 and destination
interface 40000
47.25 show access-group
Command:
show access-group in (interface {Ethernet | Ethernet IFNAME})
Functions:
Display the ACL binding status on the port.
Parameters:
IFNAME, Port name.
Command Mode:
Admin and Configuration Mode.
Usage Guide:
When not assigning interface names, all ACL tied to port will be revealed.
Examples:
Switch#show access-group
interface name: Ethernet 1/0/1

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
