Planet SGS-6341-24T4X User Manual

19-198
Parameter <tnl-id> is tunnel No.
Command Mode:
Admin Mode.
Usage Guide:
If there is not tunnel number, then information of all tunnels are shown. If there is tunnel number,
then the detailed information of specified tunnel is shown.
Example:
Switch#show ipv6 tunnel
name mode source destination nexthop
tunnel3 6to4 178.1.1.1
Displayed information
Explanation
Name
Tunnel name
Mode
Tunnel type
Source
Tunnel source ipv4 address
Destination Tunnel destination ipv4 address
Nexthop Tunnel next hop (only applies to ISATAP tunnel)
19.2.38 tunnel source
Command:
tunnel source {<ipaddress> | <ipv6address> | <interface-name>}
no tunnel source
Function:
Configure tunnel source.
Parameter:
<ipaddress> is the IPv4 address of tunnel source, must be the unicast address; <ipv6address> is
the IPv6 address of tunnel source; <interface-name> means the tunnel source address is the IPv4
address of the interface <interface-name>.
Command Mode:
Tunnel Configuration Mode.
Default Situation:
There is no IPv4/IPv6 address and interface name of tunnel source.
Usage Guide:
Set the source IPv4/IPv6 address or specify an interface name of the tunnel source address to
configure the tunnel.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
