Planet SGS-6341-24T4X User Manual

34-180
Function:
Make sure the interface and line protocols is up.
Command Mode:
Admin mode
Example:
Switch(config)#show ipv6 rip interface
Loopback is up, line protocol is up
RIPng is not enabled on this interface
Vlan1 is up, line protocol is up
Routing Protocol: RIPng
Passive interface: Disabled
Split horizon: Enabled with Poisoned Reversed
IPv6 interface address:
3000:1:1::1/64
fe80::203:fff:fe0c:cda/64
Displayed information
Explanations
Vlan1 is up, line protocol is up
Interface is Up
Routing Protocol: RIP
The routing protocol running on the interface is
RIPng
Passive interface: Disabled
Passive-interface disabled
Split horizon: Enabled with Poisoned Reversed
The split horizon is enabled with poisoned
reversed on the interface.
IP interface address:
3000:1:1::1/64
fe80::203:fff:fe01:429e/64
IPv6 address of the interface
34.21 show ipv6 rip redistribute
Command:
show ipv6 rip redistribute
Function:
Show the configuration information of redistributed other out routing to RIPng.
Default:
Not shown by default.
Command Mode:
Admin Mode and Configuration Mode.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
