Parameter:
<process-id>: Process ID, ranging from 0 to 65535. It means that GR state of all processes shown
when there is no parameter configured.
Command Mode:
Admin mode
Example:
Show GR state of all processes on GR restarter.
Switch#show ip ospf graceful-restart
OSPF process 0 graceful-restart information：
GR status :GR in progress
GR remaining time : 50
Display
Description
OSPF process 0 graceful-restart information
OSPF GR state in process 0.
GR status GR state of GR, GR in progress means switch is
processing GR
GR remaining time
Remaining time of GR
Show GR state of all processes on GR helper:
Switch#show ip ospf graceful-restart
OSPF process 0 graceful-restart information:
GR status :Helper
Neighbor ID Interface Remaining time
1.1.1.1 Vlan1 100
2.2.2.2 Vlan1 200
Display
Description
OSPF process 0 graceful-restart information
OSPF GR state of process 0.
GR status
GR state, Helper means switch is in helper mode
Neighbor ID
The router-id of restarter helped
Interface
The layer 3 interface connected with restarter
Remaining time
Remaining time of GR

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
