Planet SGS-6341-24T4X User Manual

19-174
no debug ipv6 packet
Function:
IPv6 data packets receive/send debug message.
Command Mode:
Admin Mode
Example:
Switch#debug ipv6 packet
IPv6 PACKET: rcvd, src <fe80::203:fff:fe01:2786>, dst <fe80::1>, size <64>, proto <58>, from
Vlan1
Displayed information
Explanation
IPv6 PACKET: rcvd
Receive IPv6 data report
Src <fe80::203:fff:fe01:2786>
Source IPv6 address
Dst <fe80::1>
Destination IPv6 address
size <64> Size of data report
proto <58> Protocol field in IPv6 header
from Vlan1 IPv6 data report is collected from Layer 3 port vlan1
19.2.6 debug ipv6 icmp
Command:
debug ipv6 icmp
no debug ipv6 icmp
Function:
ICMP data packets receive/send debug message.
Command Mode:
Admin Mode
Example:
Switch#debug ipv6 icmp
IPv6 ICMP: sent, type <129>, src <2003::1>, dst <2003::20a:ebff:fe26:8a49> from Vlan1
Displayed information
Explanation
IPv6 ICMP: sent
Send IPv6 data report
type <129>
Ping protocol No.
Src <2003::1>
Source IPv6 address

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
