Planet SGS-6341-24T4X User Manual

19-175
Dst <2003::20a:ebff:fe26:8a49> Destination IPv6 address
from Vlan1 Layer 3 port being sent
19.2.7 debug ipv6 nd
Command:
debug ipv6 nd [ ns | na | rs | ra | redirect ]
no debug ipv6 nd [ ns | na | rs | ra | redirect ]
Function:
Enable the debug of receiving and sending operations for specified types of IPv6 ND messages.
The ns, na, rs, ra and redirect parameters represent neighbor solicitation, neighbor advertisement,
route solicitation, route advertisement and route redirect. No specification means to enable the
debug for all five types of ND message. The no operation of this command will disable debug of
receiving and sending operations for specified types of IPv6 ND messages, while no specification
means to disable that for all five types of ND message.
Default:
The debug of receiving and sending operations for all five types of IPv6 ND messages is disabled
by default.
Command Mode:
Admin Mode
Usage Guide:
The ND protocol is an essential part of IPv6. This command can display the ND message of a
specified type for troubleshooting.
Example:
Switch#debug ipv6 nd
IPv6 ND: rcvd, type <136>, src <fe80::203:fff:fe01:2786>, dst <fe80::203:fff:fe01:59ba>
Displayed information
Explanation
IPv6 ND: rcvd
Receive ND data report
type <136>
ND Type
Src <fe80::203:fff:fe01:2786>
Source IPv6 address
Dst <fe80::203:fff:fe01:59ba> Destination IPv6 address

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
