Planet SGS-6341-24T4X User Manual

45-76
ipv6 mld snooping vlan<vlan-id> static-group <X:X::X:X> [source< X:X::X:X>] interface
[ethernet | port-channel] <IFNAME>
no ipv6 mld snooping vlan <vlan-id> static-group <X:X::X:X> [source< X:X::X:X>] interface
[ethernet | port-channel] <IFNAME>
Function:
Configure static-group on specified port of the VLAN. The no form of the command cancels this
configuration.
Parameter:
vlan-id: ranging between <1-4094>
X:X::X:X:The address of group or source.
ethernet: Name of Ethernet port
port-channel: Port aggregation
ifname: Name of interface
Command Mode:
Global mode
Default:
No configuration by default.
Usage Guide:
When a group is a static while also a dynamic group, it should be taken as a static group. Deleting
static group can only be realized by the no form of the command.
Example:
Switch(config)#ip igmp snooping vlan 1 static-group ff1e::15 source 2000::1 interface ethernet
1/0/1
45.8.16 ipv6 mld snooping vlan
suppression-query-time
Command:
ipv6 mld snooping vlan <vlan-id> suppression-query-time <value>
no ipv6 mld snooping vlan <vlan-id> suppression-query-time
Function:
Configure the suppression query time; the “no” form of this command restores the default value.
Parameter:
vlan-id: VLAN ID, valid range: <1-4094>
value: valid range: <1-65535>secs.
Command Mode:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
