Planet SGS-6341-24T4X User Manual

45-78
switch.
Mld snooping is turned on for vlan
1(querier)
On which VLAN of the switch is enabled MLD Snooping, if the
VLAN are l2-general-querier.
2. Display the detailed MLD Snooping information of vlan1
Switch#show ipv6 mld snooping vlan 1
Mld snooping information for vlan 1
Mld snooping L2 general querier :Yes(COULD_QUERY)
Mld snooping query-interval :125(s)
Mld snooping max reponse time :10(s)
Mld snooping robustness :2
Mld snooping mrouter port keep-alive time :255(s)
Mld snooping query-suppression time :255(s)
MLD Snooping Connect Group Membership
Note:*-All Source, (S)- Include Source, [S]-Exclude Source
Groups Sources Ports Exptime System Level
Ff1e::15 (2000::1) Ethernet1/0/8 00:04:14 V2
(2000::2) Ethernet1/0/8 00:04:14 V2
Mld snooping vlan 1 mrouter port
Note:"!"-static mrouter port
!Ethernet1/0/2
Displayed information
Explanation
Mld snooping L2 general querier whether or not l2-general-querier is enabled on VLAN, the querier
display status is set to could-query or suppressed
Mld snooping query-interval
Query interval time of the VLAN
Mld snooping max reponse time
Max response time of this VLAN
Mld snooping robustness
Robustness configured on the VLAN
Mld snooping mrouter port keep-alive
time
Keep-alive time of the dynamic mrouter on this VLAN
Mld snooping query-suppression
time
timeout of the VLAN as l2-general-querier at suppressed status.
MLD Snoop
ing Connect Group
Membership
Group membership of the VLAN
, namely the correspondence
between the port and （S,G）.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
