52-12
to 3600.
Command Mode:
Global Mode.
Default:
The default interval of sending fee-counting update messages is 300 seconds.
User Guide:
This command set the interval at which NAS sends fee-counting update messages. In order to
realize the real time fee-counting of users, from the moment the user becomes online, NAS will send
a fee-counting update message of this user to the RADIUS server at the configured interval.
The interval of sending fee-counting update messages is relative to the maximum number of users
supported by NAS. The smaller the interval, the less the maximum number of the users supported by
NAS; the bigger the interval, the more the maximum number of the users supported by NAS. The
following is the recommended ratio of interval of sending fee-counting update messages to the
maximum number of the users supported by NAS:
Table The recommended ratio of the interval of sending fee-counting update messages to the
maximum number of the users supported by NAS
The maximum number of users
The interval of sending fee-coun
ting update
messages(in seconds)
1~299
300（default value）
300~599
600
600~1199
1200
1200~1799
1800
≥1800
3600
Example:
The maximum number of users supported by NAS is 700, the interval of sending fee-counting
update messages 1200 seconds.
Switch(config)#radius-server accounting-interim-update timeout 1200
52.18 show aaa authenticated-user
Command:
show aaa authenticated-user
Function:
Displays the authenticated users online.
Command mode:
Admin and Configuration Mode.
Usage Guide:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
