Planet SGS-6341-24T4X User Manual

52-14
Function:
Displays the configured commands for the switch as a RADIUS client.
Command mode:
Admin and Configuration Mode.
Usage Guide:
Displays whether aaa authentication, accounting are enabled and information for key,
authentication and accounting server specified.
Example:
Switch#show aaa config（For Boolean value, 1 stands for TRUE and 0 for FALSE）
----------------- AAA config data ------------------
Is Aaa Enabled = 1 :1 means AAA authentication is enabled, 0 means is not enabled
Is Account Enabled= 1 :1 means AAA account is enabled, 0 means is not enabled
MD5 Server Key = yangshifeng : Authentication key
authentication server sum = 2 :Configure the number of authentication server
authentication server[0].sock_addr = 2:100.100.100.60.1812 :The address protocol
group, IP and interface number of the first authentication server
.Is Primary = 1 :Is the primary server
.Is Server Dead = 0 :The server whether dead
.Socket No = 0 :The local socket number lead to this server
authentication server[1].sock_addr = 10:2004:1:2::2.1812
.Is Primary = 0
.Is Server Dead = 0
.Socket No = 0
accounting server sum = 2 :Configure the number of the accounting server
accounting serv
er[0].sock_addr = 2:100.100.100.65.1813 :The address protocol group,
IP and interface number of the accounting server
.Is Primary = 1 :Is primary server
.Is Server Dead = 0 :This server whether dead
.Socket No = 0 :The local socket number lead to this
server
accounting server[1].sock_addr = 10:2004::7.1813
.Is Primary = 1
.Is Server Dead = 0
.Socket No = 0
Time Out = 5s :After send the require packets, wait for response time out
Retransmit = 3 :The number of retransmit

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
