Planet SGS-6341-24T4X User Manual

60-10
members in the same Standby cluster, this property should be set to a same value. To Backup, the
value of master_down_interval is three times that of adver_interval. Extraordinary large traffic or
timer setting differences between routers (or L3 Ethernet switches) may result in
master_down_interval and invoke instant status changes. Such situations can be avoided through
extending adver_interval interval and setting longer preemptive delay time.
Example:
Configuring vrrp Timer value to 3
Switch(Config-Router-Vrrp)# advertisement-interval 3
60.2 circuit-failover
Commands:
circuit-failover {IFNAME | Vlan <ID>} <value_reduced>
no circuit-failover
Function:
Configures the VRRP monitor interface.
Parameters:
< IFNAME > is the name for the interface to be monitored.
<value_reduced> stands for the amount of priority decreased, the default value is 1~253.
Default:
Not configured by default.
Command mode:
VRRP protocol configuration mode
Usage Guide:
The interface monitor function is a valuable extension to backup function, which not only enable
VRRP to provide failover function on router (or L3 Ethernet switch) fail, but also allow decreasing the
priority of a router (or L3 Ethernet switch) to ensure smooth implementation of backup function when
status of that network interface is down.
When this command is used, if the status of an interface monitored turns from up to down, then the
priority of that very router (or L3 Ethernet switch) in its Standby cluster will decrease, lest Backup
cannot changes its status due to lower priority than the Master when the Master fails.
Example:
Configuring VRRP monitor interface to vlan 2 and decreasing amount of priority to 10.
Switch(Config-Router-Vrrp)# circuit-failover vlan 2 10

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
