Planet SGS-6341-24T4X User Manual

67-5
Command Mode:
Global Mode.
Default:
The default value is 0.
Usage Guide:
When sample packet is sent to the CPU, it is recommended not to assign high priority for the packet
so that regular receiving and sending of other protocol packet will not be interfered. The higher the
priority value is set, the higher its priority will be.
Example:
Configure the priority when sFlow receives packet from the hardware at global mode.
switch (config)#sflow priority 1
67.8 sflow rate
Command:
sflow rate { input <input-rate> | output <output-rate >}
no sflow rate [input | output]
Function:
Configure the sample rate of the sFlow hardware sampling. The “no” form of this command deletes
the sampling rate value.
Parameter:
<input-rate> is the rate of ingress group sampling, the valid range is 1000~16383500.
<output-rate> is the rate of egress group sampling, the valid range is 1000~16383500.
Command Mode:
Port Mode.
Default:
No default value.
Usage Guide:
The traffic sampling will not be performed if the sampling rate is not configured on the port. And if
the ingress group sampling rate is set to 10000, this indicates there will be one group be sampled
every 10000 ingress groups.
Example:
Configure the ingress sample rate on port e1/0/1 to 10000 and the egress sample rate to 20000.
Switch(Config-If-Ethernet1/0/1)#sflow rate input 10000
Switch(Config-If-Ethernet1/0/1)#sflow rate output 20000

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
