Planet SGS-6341-24T4X User Manual

77-10
<mem-id> is the member device number under the VSF mode, range is 1 to 16; <slot-id> is the
number of the slot the chip resides, all the slots are 1 for the cassette devices.
Default:
All chip information will be listed by default if mem-id and slot-id are not specified
Command Mode:
Admin Mode.
Example:
Switch#show member 13 slot 1
--------------------member :13--------------------
Inserted : YES
Module type : Switch
Work mode : STANDBY MASTER
Work state : RUNNING
Software package version : 7.0.3.0(R0075.0011)
Bootrom version : 7.2.2
CPLD version : N/A
Hardware version : 1.0.1
Part number : N110900062
Manufacture date : 2011/03/10
Temperature : 39C/102F
Uptime : 0 weeks, 0 days, 1 hours, 37 minutes
77.12 debug vsf packet detail <alive | all | config |
member-infor | probe | routing | topo>
Command:
debug vsf packet detail <alive | all | config | member-infor | probe | routing | topo>
no debug vsf packet detail <alive | all | config | member-infor | probe | r routing | topo>
Function:
Enable all kinds of VSF protocol packets viewing on-off. The no command disables it.
Parameters:
<alive>：keep-alive packets; <all>：enable all VSF protocol packets; <config>：Configure the
information packet, this parameter means the packets interaction in viewing the config. In this stage,
VSF members achieves the necessary information of master election through packets interaction to
elect the master and standby master; <member-infor>：member information packets; <probe>：

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
