Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-137
The last 5 second input rate 0 bytes/sec, 0 packets/sec
The last 5 second output rate 0 bytes/sec, 0 packets/sec
Input packets statistics:
0 input packets, 0 bytes, 0 no buffer
0 unicast packets, 0 multicast packets, 0 broadcast packets
0 input errors, 0 CRC, 0 frame alignment, 0 overrun, 0 ignored
0 abort, 0 length error, 0 pause frame
Output packets statistics:
0 output packets, 0 bytes, 0 underruns
0 unicast packets, 0 multicast packets, 0 broadcast packets
0 output errors, 0 collisions, 0 late collisions, 0 pause frame
Show the important information of all layer 2 ports:
Switch#show interface ethernet status
Codes: A-Down - administratively down, a - auto, f - force, G - Gigabit
Interface Link/Protocol Speed Duplex Vlan Type Alias Name
1/0/1 UP/UP f-100M f-full 1 G-TX
1/0/2 UP/UP a-100M a-full trunk G-TX
1/0/3 UP/DOWN auto auto 1 G-TX
1/0/4 A-Down/DOWN auto auto 1 G-TX
…
Show the package number statistics information of all layer 2 ports:
Switch#Show interface ethernet counter packet
Interface Unicast(pkts) BroadCast(pkts) MultiCast(pkts) Err(pkts)
1/0/1 IN 12,345,678 12,345,678,9 12,345,678,9 4,567
OUT 23,456,789 34,567,890 5,678 0
1/0/2 IN 0 0 0 0
OUT 0 0 0 0
1/0/3 IN 0 0 0 0
OUT 0 0 0 0
1/0/4 IN 0 0 0 0
OUT 0 0 0 0
…
Show the rate statistics information of all layer 2 ports:
Switch＃Show interface ethernet counter rate
Interface IN(pkts/s) IN(bytes/s) OUT(pkts/s) OUT(bytes/s)
1/0/1 5m 13,473 12,345,678 12,345 1,234,567
5s 135 65,800 245 92,600

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
