Planet SGS-6341-24T4X User Manual

14-122
-------------- ------- --------- --- ---- ------------------ -------
Ethernet1/0/1 128.001 0 FWD MSTR 32768.00030f010e30 128.001
Ethernet1/0/2 128.002 0 BLK ALTR 32768.00030f010e30 128.002
Displayed Information
Description
Bridge Information
Standard
STP version
Bridge MAC
Bridge MAC address
Bridge Times
Max Age, Hello Time and Forward Delay of the bridge
Force Version
Version of STP
Instance Information
Self Bridge Id
The priority and the MAC address of the current bridge for
the current instance
Root Id
The priority and the MAC address of the root bridge for the
current instance
Ext.RootPathCost
Total cost from the current bridge to the root of the entire
network
Int.RootPathCost Cost from the current bridge to the region root of the current
instance
Root Port ID
Root port of the current instance on the current bridge
MSTP Port List Of The Current
Instance
PortName
Port name
ID
Port priority and port index
ExtRPC
Port cost to the root of the entire network
IntRPC
Cost from the current port to the region root of the current
instance
State
Port status of the current instance
Role
Port role of the current instance
DsgBridge Upward designated bridge of the current port in the current
instance
DsgPort
Upward designated port of the current port in the current
instance

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
