Planet SGS-6341-24T4X User Manual

27-60
Show information
Explanation
Address pools
To configure the number of DHCPv6 address pools;
Active bindings
The number of auto assign addresses;
Expiried bindings
The number of expiried bindings;
Malformed message
The number of malformed messages;
Message Recieved
The statistic of received DHCPv6 packets.
DHCP6SOLICIT
The number of DHCPv6 SOLICIT packets.
DHCP6ADVERTISE
The number of DHCPv6 ADVERTISE packets.
DHCPv6REQUEST
The number of DHCPv6 REQUEST packets.
DHCP6REPLY
The number of DHCPv6 REPLY packets.
DHCP6RENEW
The number of DHCPv6 RENEW packets.
DHCP6REBIND
The number of DHCPv6 REBIND packets.
DHCP6RELEASE
The number of DHCPv6 RELEASE packets.
DHCP6DECLINE
The number of DHCPv6 DECLINE packets.
DHCP6CONFIRM
The number of DHCPv6 CONFIRM packets.
DHCP6RECONFIGURE
The number of DHCPv6 RECONFIGURE packets.
DHCP6INFORMREQ
The number of DHCPv6 INFORMREQ packets.
DHCP6RELAYFORW
The number of DHCPv6 RELAYFORW packets.
DHCP6RELAYREPLY
The number of DHCPv6 RELAYREPLY packets.
Message Send
The statistic of sending DHCPv6 packets
DHCP6SOLICIT
The number of DHCPv6 SOLICIT packets.
DHCP6ADVERTISE
The number of DHCPv6 ADVERTISE packets.
DHCPv6REQUEST
The number of DHCPv6 REQUEST packets.
DHCP6REPLY
The number of DHCPv6 REPLY packets.
DHCP6RENEW
The number of DHCPv6 RENEW packets.
DHCP6REBIND
The number of DHCPv6 REBIND packets.
DHCP6RELEASE
The number of DHCPv6 RELEASE packets.
DHCP6DECLINE
The number of DHCPv6 DECLINE packets.
DHCP6CONFIRM
The number of DHCPv6 CONFIRM packets.
DHCP6RECONFIGURE
The number of DHCPv6 RECONFIGURE packets.
DHCP6INFORMREQ
The number of DHCPv6 INFORMREQ packets.
DHCP6RELAYFORW
The number of DHCPv6 RELAYFORW packets.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
