Planet SGS-6341-24T4X User Manual

30-90
Function:
This command is use to enable the DHCP snooping debug switch to debug the communication
information between DHCP snooping and helper server.
Command Mode:
Admin Mode.
Usage Guide:
Debug the information of communication messages received and sent by DHCP snooping and
helper server.
30.6 enable trustview key
Command:
enable trustview key {0 | 7} <password>
no enable trustview key
Function:
To configure DES encrypted key for private packets, this command is also the switch for the private
packets encrypt and hash function enabled or not.
Parameter:
<password> is character string length less than 16, which use as encrypted key. 0 for un-encrypted
text for the password, while 7 for encrypted.
Command Mode:
Global Mode.
Default:
Disabled.
Usage Guide:
The switch communicates with the TrustView management system through private protocols. By
default these packets are not encrypted. In order to prevent spoofing, it can be configured to encrypt
these packets. And at the same time, the same password should be configured on TrustView
server.
Example:
Enable encrypt or hash function of private message.
Switch(config)# enable trustview key 0 digitalchina

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
