30-106
value is 9119.
src_addr: The local management IP address of the switch, in dotted-decimal notation.
sencondary: Whether it is a secondary SERVER address.
Command Mode:
Global mode
Default Settings:
There is no HELPER SERVER address by default.
Usage Guide:
DHCP SNOOPING will send the monitored binding information to HELPER SERVER to save it. If
the switch starts abnormally, it can recover the binding data from HELPER SERVER. The HELPER
SERVER function usually is integrated into server packet. The DHCP SNOOPING and HELPER
SERVER use the UDP protocol to communicate, and guarantee the arrival of retransmitted data.
HELPER SERVER configuration can also be used to sent DOT1X user data from the server, the
detail of usage is described in the chapter of “dot1x configuration”.
Two HELPER SERVER addresses are allowed, DHCP SNOOPING will try to connect to PRIMARY
SERVER in the first place. Only when the PRIMARY SERVER is unreachable, will the switch c
HELPER SERVER connects to SECONDARY SERVER.
Please pay attention:
source address is the effective management IP address of the switch, if the management IP
address of the switch changes, this configuration should be updated in time.
Example:
Set the local management IP address as 100.1.1.1, primary HELPER SERVER address as
100.1.1.100 and the port as default value.
switch(config)#interface vlan 1
switch(Config- If-Vlan1)#ip address 100.1.1.1 255.255.255.0
switch(Config-if-Vlan1)exit
switch(config)#ip user helper-address 100.1.1.100 source 100.1.1.1
30.29 ip user private packet version two
Command:
ip user private packet version two
no ip user private packet version two
Function:
The switch choose private packet version two to communicate with trustview.
Command Mode:
Global Mode.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
