Planet SGS-6341-24T4X User Manual

33-152
33.21 ip rip split-horizon
Command:
ip rip split-horizon [poisoned]
no ip rip split-horizon
Function:
Enable split horizon. The “no ip rip split-horizon” disables the split horizon.
Parameter:
[poisoned] means configure the split horizon with poison reverse.
Default:
Split Horizon with poison reverse by default.
Command Mode:
Interface Configuration Mode.
Usage Guide:
The split horizon is for preventing the Routing Loops, namely preventing the layer 3 switches from
broadcasting the routes which is learnt from the same interface on which the route to be
broadcasted.
Example:
Switch# config terminal
Switch(config)# interface vlan 1
Switch(Config-if-Vlan1)# ip rip split-horizon poisoned
33.22 key
Command:
key <keyid>
no key <keyid>
Function:
This command is for managing and adding keys in the key chain. The “no key <keyid>“command
deletes one key.
Parameter:
<keyid> is key ID, ranging between 0-2147483647.
Command Mode:
Keychain mode and keychain-key mode
Usage Guide:
The command permits entering the keychain-key mode and set the passwords corresponding to the

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
