Planet SGS-6341-24T4X User Manual

33-155
Switch# config terminal
Switch(config)# router rip
Switch(config-router)# maximum-prefix 150
33.26 neighbor
Command:
neighbor <A.B.C.D>
no neighbor <A.B.C.D>
Function:
Specify the destination address requires targeted-peer sending. The “no neighbor
<A.B.C.D>“command cancels the specified address and restores all gateways to trustable.
Parameter:
<A.B.C.D> is the specified destination address for the sending, shown in dotted decimal notation.
Default:
Not sending to any targeted-peer destination address.
Command Mode:
Router mode
Usage Guide:
When used accompany with passive-interface command it can be configured to only sending
routing messages to specific neighbor.
Example:
Switch# config terminal
Switch(config)# router rip
Switch(config-router)# neighbor 1.1.1.1
Related Command:
passive-interface
33.27 network
Command:
network <A.B.C.C/M|ifname>
no network <A.B.C.C/M|ifname>
Function:
Configure the RIP protocol network.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
