Planet SGS-6341-24T4X User Manual

35-223
[{<linkstate_id>| self-originate |adv-router <advertiser_router>}] | opaque-area [{<linkstate_id>|
self-originate |adv-router <advertiser_router>}] opaque-as [{<linkstate_id>| self-originate
|adv-router <advertiser_router>}]|opaque-link [{<linkstate_id>| self-originate |adv-router
<advertiser_router>}] | router [{<linkstate_id>| self-originate |adv-router <advertiser_router>}]|
summary [{<linkstate_id>| self-originate |adv-router <advertiser_router>}] |self-originate |
max-age }]
Function:
Display the OSPF link state data base messages.
Parameter:
<process-id> is the process ID, ranging between 0~65535
<linkstate_id> Link state ID, shown in point divided demical system
<advertiser_router> is the ID of Advertising router, shown in point divided demcial IP address
format
Default:
Not displayed
Command Mode:
Admin and configuration mode
Usage Guide:
According to the output messages of this command, we can view the OSPF link state database
messages.
Example:
Switch#show ip ospf database
Router Link States (Area 0.0.0.2)
Link ID ADV Router Age Seq# CkSum Link count
192.168.1.2 192.168.1.2 254 0x80000031 0xec21 1
192.168.1.3 192.168.1.3 236 0x80000033 0x0521 2
Net Link States (Area 0.0.0.2)
Link ID ADV Router Age Seq# CkSum
20.1.1.2 192.168.1.2 254 0x8000002b 0xece4
Summary Link States (Area 0.0.0.2)
Link ID ADV Router Age Seq# CkSum Route
6.1.0.0 192.168.1.2 68 0x8000002b 0x5757 6.1.0.0/22
6.1.1.0 192.168.1.2 879 0x8000002a 0xf8bc 6.1.1.0/24

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
