Planet SGS-6341-24T4X User Manual

37-282
Switch(config-af)#import map map1
Switch#show ip bgp vpn all
Network Next Hop Metric LocPrf Weight Path
Route Distinguisher: 100:10 (Default for VRF DC1)
*> 11.1.1.0/24 11.1.1.64 0 0 200 ?
*>i15.1.1.0/24 10.1.1.68 0 100 655 300 ?
*> 20.1.1.0/24 11.1.1.64 0 0 200 ?
*>i100.1.1.0/24 10.1.1.68 0 100 655 300 ?
Route Distinguisher: 100:10
*>i15.1.1.0/24 10.1.1.68 0 100 0 300 ?
*>i100.1.1.0/24 10.1.1.68 0 100 0 300 ?
As we can see, the weight of the route from the VPN changes to 655 after introduced into VRF
DC1.
37.39 ip as-path access-list
Command:
ip as-path access-list <.LINE> {<permit>|<deny>} <LINE>
no ip as-path access-list <.LINE> {<permit>|<deny>} <LINE>
Function:
Configure the AS-PATH access-list. The “no ip as-path access-list <.LINE> {<permit>|<deny>}
<LINE>” command deletes this access-list.
Parameter:
<.LINE>: name of access-list.
<LINE>: matched strings in the AS-PATH.
Command Mode:
Global mode.
Usage Guide:
Use this command to configure the access-list related to AS-PATH, so to supply the conditions for
pass/filter.
Example:
Configure the access-list named ASPF, filter the AS-PATH contained route 100.
Switch(config)#ip as-path access-list ASPF deny ^100$

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
