Planet SGS-6341-24T4X User Manual

37-297
Configure the maximum number of route prefix from neighbor 10.1.1.64 is 12, and it warns when the
number of route prefix reaches 6, and the connection will be cut when the number hit 13.
Switch(config-router)#neighbor 10.1.1.64 maximum-prefix 12 50
37.59 neighbor next-hop-self
Command:
neighbor {<ip-address>|<TAG>} next-hop-self
no neighbor {<ip-address>|<TAG>} next-hop-self
Function:
Ask the neighbor to point the route nexthop sent by the local side to local side. The “no neighbor
{<ip-address>|<TAG>} next-hop-self” command cancels this configuration.
Parameter:
<ip-address>: Neighbor IP address.
<TAG>: Name of peer group.
Default:
Not configured by default.
Command Mode:
BGP route mode and address-family mode
Usage Guide:
In the EBGP environment, the nexthop will automatically point to the source neighbor. However in
IBGP environment, the nexthop remains the same for route in the same segment. If it is not
broadcast network, errors will be encountered. This command is for force self as the nexthop of the
neighbor under IBGP.
Example:
Switch(config-router)#neighbor 10.1.1.66 next-hop-self
37.60 neighbor override-capability
Command:
neighbor {<ip-address>|<TAG>} override-capability
no neighbor {<ip-address>|<TAG>} override-capability
Function:
Whether enable overriding capability negotiation. The “no neighbor {<ip-address>|<TAG>}
override-capability” command restores the capability negotiation.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
