Planet SGS-6341-24T4X User Manual

44-96
{<acl_num | acl_name>} is SN or name of access-list, value range of acl_num is from 1 to 99.
Default:
Default no filter condition
Command Mode:
Interface Configuration Mode
Usage Guide:
Configure interface to filter groups, permit or deny some group joining.
Example:
Configure interface vlan1 to permit group 224.1.1.1, deny group 224.1.1.2.
Switch (config)#access-list 1 permit 224.1.1.1 0.0.0.0
Switch (config)#access-list 1 deny 224.1.1.2 0.0.0.0
Switch (config)#interface vlan 1
Switch(Config-if-Vlan1)#ip igmp access-group 1
44.9.5 ip igmp immediate-leave
Command:
ip igmp immediate-leave group-list {<number>|<name>}
no ip igmp immediate-leave
Function:
Configure IGMP working in immediate-leave mode, that is, when the host transmits member identity
report of equivalent to leave a group, router does not transmit query, it directly confirms there is no
member of this group in subnet; the “no ip igmp immediate-leave” command cancels
immediate-leave mode.
Parameter:
<number> is access-list SN, value is from 1 to 99.
<name> is access-list name.
Default:
Interface default and no immediate-leave group of configuration after finished product
Command Mode:
Interface Configuration Mode
Usage Guide:
The command only can apply in only one host condition in subnet.
Example:
Configure immediate-leave mode on access-group list 1
Switch (Config-if-Vlan1)#ip igmp immediate-leave group-list 1
Switch (Config-if-Vlan1)#

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
