Planet SGS-6341-24T4X User Manual

44-108
Default:
IGMP Snooping is disabled by default.
Usage Guide:
To configure IGMP Snooping on specified VLAN, the global IGMP Snooping should be first enabled.
Disable IGMP Snooping on specified VLAN with the “no ip igmp snooping vlan <vlan-id>”
command.
Example:
Enable IGMP Snooping for VLAN 100 in Global Mode.
Switch(config)#ip igmp snooping vlan 100
44.10.7 ip igmp snooping vlan immediate-leave
Command:
ip igmp snooping vlan <vlan-id> immediate-leave
no ip igmp snooping vlan <vlan-id> immediate-leave
Function:
Enable the IGMP Snooping fast leave function for the specified VLAN; the “no ip igmp snooping
vlan <vlan-id> immediate-leave” command disables the IGMP Snooping fast leave function.
Parameter:
<vlan-id> is the VLAN number specified.
Command mode:
Global Mode
Default:
This function is disabled by default.
Usage Guide:
Enable immediate-leave function of the IGMP Snooping in specified VLAN; the“no” form of this
command disables the immediate-leave function of the IGMP Snooping.
Example:
Enable the IGMP Snooping fast leave function for VLAN 100.
Switch(config)#ip igmp snooping vlan 100 immediate-leave
44.10.8 ip igmp snooping vlan l2-general-querier
Command:
ip igmp snooping vlan < vlan-id > l2-general-querier
no ip igmp snooping vlan < vlan-id > l2-general-querier

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
