Planet SGS-6341-24T4X User Manual

44-115
44.10.18 ip igmp snooping vlan report source-address
Command:
ip igmp snooping vlan <vlan-id> report source-address <A.B.C.D>
no ip igmp snooping vlan <vlan-id> report source-address
Function:
Configure forward report source-address for IGMP, the “no ip igmp snooping vlan <vlan-id>
report source-address” command restores the default setting.
Parameter:
vlan-id: VLAN ID range<1-4094>;
A.B.C.D: IP address, can be 0.0.0.0.
Command Mode:
Global Mode.
Default:
Disabled.
Usage Guide:
Default configuration is recommended here. If IGMP snooping needs to be configured, the source
address for forwarded IGMP messages can be 0.0.0.0. If it is required by the upstream that IGMP
messages should use the same network address, the source address of IGMP messages should be
configured to be the same with upstream.
Example:
Switch (config)#ip igmp snooping vlan 2 report source-address 10.1.1.1
44.10.19 ip igmp snooping vlan specific-query-mrsp
Command:
ip igmp snooping vlan <vlan-id> specific-query-mrsp <value>
no ip igmp snooping vlan <vlan-id> specific-query-mrspt
Function:
Configure the maximum query response time of the specific group or source, the no command
restores the default value.
Parameters:
<vlan-id>: the specific VLAN ID, the range from 1 to 4094.
<value>: the maximum query response time, unit is second, the range from 1 to 25, default value is
1.
Command Mode:
Global mode

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
