Planet SGS-6341-24T4X User Manual

44-127
PROXY and PIM configuration. To be mentioned, this command cannot be applied with DVMRP
configuration.
Example:
To enable SSM configuration on the switch, and specify the address in access-list 23 as the filter
address for SSM.
Switch(config)# access-list 23 permit host-source 224.1.1.1
Switch(config)#ip multicast ssm range 23
44.11.16 ip pim bsr-border
Command:
ip pim bsr-border
no ip pim bsr-border
Function:
To configure the PIM enabled port to consider all multicast source is directly connected; the no form
of this command will remove the configuration.
Command Mode:
Interface Configuration Mode.
Default:
Disabled.
Usage Guide:
Configuring the multicast source to be considered as directly connected for the PIM enabled port is
used to determine the identity of DR and ORIGINATOR.
Example:
To configure PIM enabled VLAN 2 as the port for BSR BORDER. For all the multicast flow from
external network through VLAN 2, the switch will consider the multicast source is directly connected
to the switch.
Switch(config)#interface vlan 2
Switch(Config-if-Vlan2)#ip pim bsr-border
44.11.17 show debugging igmp proxy
Command:
show debugging igmp proxy
Function:
Display the status of debug switch of IGMP Proxy.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
