Planet SGS-6341-24T4X User Manual

45-41
Command:
ipv6 pim anycast-rp <anycast-rp-addr> <other-rp-addr>
no ipv6 pim anycast-rp <anycast-rp-addr> <other-rp-addr>
Function:
Configure ANYCAST RP address（ARA）and the unicast addresses of other RP communicating with
this router(as a RP). The no operation of this command will cancel the unicast address of another
RP in accordance with the configured RP address.
Parameters:
anycast-rp-addr: RP address, the current absence of the candidate interface in accordance with
the address is allowed.
other-rp-addr: The unicast address of other RP communicating with this router(as a RP).
Command Mode:
Global Configuration Mode.
Default:
There is no configuration by default.
Usage Guide:
1. The anycast-rp-addr configured on this router (as a RP) is actually the RP address configured on
multiple RP in the network, in accordance with the address of RP candidate interface (or Loopback
interface). The current absence of the candidate interface in accordance with the address is allowed
when configuring.
2. Configure the other-rp-address of other RPs communicating with this router (as a RP). The
unicast address identifies other RP, and is used to communicate with the local router.
3. Once this router (as a RP) receives the register message from a DR unicast, it should forward it
to other RP in the network to notify all the RP in the network of the source (S.G) state. While
forwarding, the router will change the destination address of the register message into
other-rp-address.
4. Multiple other-rp-addresses can be configured in accordance with one anycast-rp-addr, once the
register message from a DR is received, it should be forwarded to all of these other RP one by one.
Example:
Configure other-rp-address in global configuration mode.
Switch(config)#ipv6 pim anycast-rp 2000::1 2004::2
45.4.4 ipv6 pim anycast-rp self-rp-address
Command:
ipv6 pim anycast-rp self-rp-address <self-rp-addr>
no ipv6 pim anycast-rp self-rp-address

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
