Planet SGS-6341-24T4X User Manual

45-43
ifname: the specified name of the interface.
A:B::C:D/M: the ip prefix and mask.
<priority>: the priority of RP election, ranging from 0 to 255, the default value is 192, the smaller
the value is the higher the priority is.
Command Mode:
Global Configuration Mode.
Default Setting:
No RP interface is configured by default.
Usage Guide:
In order to support ANYCAST RP function, new rule allows configuring a Loopback interface to be
the RP candidate interface, the RP candidate interface should be currently unique, and the address
of which should be added into the router to make sure that PIM router can find the nearest RP. The
“no ipv6 pim rp-candidate” command can be used to cancel the RP candidate.
Example:
Configure Loopback1 interface as the RP candidate interface in global configuration mode.
Switch(config)# ipv6 pim rp-candidate loopback1
45.4.6 show debugging ipv6 pim
Command:
show debugging ipv6 pim
Command Mode:
Admin and Configuration Mode.
Usage Guide:
The current state of ANYCAST RP debug switch.
Example:
Switch(config)#show debugging ipv6 pim
Debugging status:
PIM anycast-rp debugging is on
45.4.7 show ipv6 pim anycast-rp first-hop
Command:
show ipv6 pim anycast-rp first-hop
Command Mode:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
