47-6
20(0x14): PIM V1 packet
Particular notice:
The packet types included here are not the types excluding IP OPTION. Normally, IGMP packet
contains OPTION fields, and such configuration is of no use for this type of packet. If you want to
configure the packets containing OPTION, please directly use the manner where OFFSET is
configured.
Examples:
Create the numeric extended access-list whose serial No. is 110. deny icmp packet to pass, and
permit udp packet with destination address 192. 168. 0. 1 and destination port 32 to pass.
Switch(config)#access-list 110 deny icmp any any-destination
Switch(config)#access-list 110 permit udp any host-destination 192.168.0.1 d-port 32
47.4 access-list (ip standard)
Command:
access-list <num> {deny | permit} {{<sIpAddr> <sMask >} | any-source| {host-source
<sIpAddr>}}
no access-list <num>
Functions:
Create a numeric standard IP access-list. If this access-list exists, then add a rule list; the “no
access-list <num>“ operation of this command is to delete a numeric standard IP access-list.
Parameters:
<num> is the No. of access-list, 100-199; <sIpAddr> is the source IP address, the format is dotted
decimal notation; <sMask > is the reverse mask of source IP, the format is dotted decimal notation.
Command Mode:
Global mode
Default:
No access-lists configured.
Usage Guide:
When the user assign specific <num> for the first time, ACL of the serial number is created, then
the lists are added into this ACL.
Examples:
Create a numeric standard IP access-list whose serial No. is 20, and permit date packets with
source address of 10.1.1.0/24 to pass, and deny other packets with source address of 10.1.1.0/16.
Switch(config)#access-list 20 permit 10.1.1.0 0.0.0.255
Switch(config)#access-list 20 deny 10.1.1.0 0.0.255.255

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
