Planet SGS-6341-24T4X User Manual

47-10
enabled to form a match when in connection; precedence (optional) packets can be filtered by
priority which is a number from 0-7; tos (optional) packets can be filtered by service type which ia
number from 0-15; icmp-type (optional) ICMP packets can be filtered by packet type which is a
number from 0-255; icmp-code (optional) ICMP packets can be filtered by packet code which is a
number from 0-255; igmp-type (optional) ICMP packets can be filtered by IGMP packet name or
packet type which is a number from 0-255; <time-range-name>, name of time range
Command Mode:
Global mode
Default Configuration:
No access-list configured.
Usage Guide:
When the user assign specific <num> for the first time, ACL of the serial number is created, then the
lists are added into this ACL; the access list which marked 3200-3299 can configure not continual
reverse mask of IP address.
Examples:
Permit the passage of TCP packet with source MAC 00-12-34-45-XX-XX, any destination MAC
address, source IP address 100.1.1.0 0.255.255.255, and source port 100 and destination interface
40000.
Switch(config)#access-list 3199 permit 00-12-34-45-67-00 00-00-00-00-FF-FF
any-destination-mac tcp 100.1.1.0 0.255.255.255 s-port 100 any-destination d-port 40000
47.7 access-list(mac standard)
Command:
access-list <num> {deny|permit} {any-source-mac | {host-source-mac <host_smac> } |
{<smac> <smac-mask>} }
no access-list <num>
Functions:
Define a standard numeric MAC ACL rule, no command deletes a standard numeric MAC ACL
access-list rule.
Parameters:
<num> is the access-list No. which is a decimal’s No. from 700-799; deny if rules are matching,
deny access; permit if rules are matching, permit access; <host_smac>, <sumac> source MAC
address; <sumac-mask> mask (reverse mask) of source MAC address.
Command Mode:
Global mode

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
