48-15
no dot1x timeout tx-period
Function:
Sets the interval for the supplicant to re-transmit EAP request/identity frame; the “no dot1x timeout
tx-period” command restores the default setting.
Parameters:
<seconds> is the interval for re-transmission of EAP request frames, in seconds; the valid range is
1 to 65535.
Command mode:
Global Mode.
Default:
The default value is 30 seconds.
Usage Guide:
Default value is recommended.
Example:
Setting the EAP request frame re-transmission interval to 1200 seconds.
Switch(config)#dot1x timeout tx-period 1200
48.23 dot1x unicast enable
Command:
dot1x unicast enable
no dot1x unicast enable
Function:
Enable the 802.1x unicast passthrough function of switch; the no operation of this command will
disable this function.
Command mode:
Global Configuration Mode.
Default:
The 802.1x unicast passthrough function is not enabled in global mode.
Usage Guide:
The 802.1x unicast passthrough authentication for the switch must be enabled first to enable the
802.1x unicast passthrough function, then the 802.1x function is configured.
Example:
Enabling the 802.1x unicast passthrough function of the switch and enable the 802.1x for port 1/0/1.
Switch(config)#dot1x enable
Switch(config)# dot1x unicast enable

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
