Planet SGS-6341-24T4X User Manual

49-3
When the number limitation function debug of MAC on the port, if the number of dynamic MAC and
the number of MAC on the port is larger than the max number allowed, users will see debug
information. ”no debug switchport mac count” command is used to disable the number limitation
function debug of MAC on the port.
Command Mode:
Admin Mode
Usage Guide:
Display the debug information of the number of dynamic MAC on the port.
Examples:
Switch#debug switchport mac count
%Jun 14 16:04:40 2007 Current
mac count 21 is more than or equal to the maximum limit in
port Ethernet1/0/1
!!%Jun 14 16:04:40 2007 Mac learning will be stopped and some mac will be delete !!
49.5 debug switchport nd count
Command:
debug switchport nd count
no debug switchport nd count
Function:
When the number limitation function debug of ND on the port, if the number of dynamic ND and the
number of ND on the port is larger than the max number allowed, users will see debug
information. ”no debug switchport nd count” command is used to disable the number limitation
function debug of ND on the port.
Command Mode:
Admin Mode
Usage Guide:
Display the debug information of the number of dynamic ND on the port
Examples:
Switch#debug switchport arp count
%Jun 14 16:04:40 2007 Current neighbor
count 21 is more than or equal to the maximum limit
in port Ethernet1/0/1
!!%Jun 14 16:04:40 2007 Neighbor learning will be stopped and some mac will be delete !!

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
