Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 3-21
Error Messages and Codes
4 Check all pins on the REGISNS
Harness PL4.1.4 for continuity.
1. Disconnect P/J181 and P/J18.
2. Check continuity between J181 <=>
J18
Go to Step 5. Replace the
Registration
Sensor
Harness.
5 Check the Registration Sensor signal.
Block the Registration Sensor.
Is the voltage across P/J18-3 <=> P/
J18-2
0 V?
Replace
Registration
Sensor
(
page 8-39).
Go to Step 6.
6 If possible, print a Test Print from
Tray 1 (MPT).
Does the Main Motor function
properly?
Go to Step 16. Go to Step 7.
7 Test the Main Drive Assembly.
Run the Service Diagnostics Main
Motor test.
Does the Main Motor turn?
Replace the
Engine Control
Board
(
page 8-106).
Go to Step 8.
8 Check for +24 V to the Main Drive
Motor
1. Disconnect P/J481.
2. Close the Interlock Switch while
testing.
Is there +24 V across J481-10 <=>
J481-8?
Go to Step 12. Go to Step 9.
9 Test the Interlock Switch.
Run the Service Diagnostics Interlock
Switch test.
Does the Interlock Switch function
correctly?
Go to Step 11. Replace the
parts
concerned.
10 Check for +5 V to the Interlock Switch
Disconnect P/J161.
Is there +5 V across P161-1 <=> P161-
2?
Replace the LVPS. Replace the
Interlock Switch
(
page 8-102).
11 Check all pins on the FAN/PHD/MOT
Harness PL10.1.9 for continuity.
1. Disconnect P/J48 and P/J481.
2. Check continuity between J48 <=>
J481.
Replace Main
Drive Motor
Replace FAN/
PHD/MOT
Harness.
12 Check Turn Roller function.
1. Perform Steps 1 through 3 on
(page 8-22).
2. Open and close the front door.
3. Observe the Turn Roller.
Does the Turn Roller turn while the
machine is warming up?
Go to Step 16. Go to Step 13
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
