Phaser 6300/6350/6360 Color Laser Printer Service Manual 3-31
Error Messages and Codes
14 Test the Feed Solenoid.
Run the Service Diagnostics Feed Solenoid
test.
Does the solenoid function correctly?
Check the feed
solenoid
stopper and
replace if
necessary.
Go to Step 15.
15 Check for +24 V to the Feed Solenoid.
1. Disconnect P/J824
2. Close the Interlock Switch while testing.
Is there +24 V across P824-2 <+>ground?
Go to Step 17. Go to Step 16.
16 Check all pins on the OPFDR Harness
PL11.3.24 for continuity.
1. Disconnect P/J85 and P/J824.
2. Check continuity between J85 <=>
P824.
Go to Step 17. Replace the
OPFDR
Harness.
17 Test the Feed Solenoid resistance.
Disconnect P/J824.
Is J824-1 <=> J824-2 less than 100Ω?
Go to Step 17. Replace the
Feed Solenoid
(Part of the
Paper Pick
Assembly).
18 Check all pins on the OPFPLG Harness
PL3.2.11 for continuity.
1. Disconnect P/J171 and P/J17.
2. Check continuity between P171 <=>
J17.
Replace the
Engine Control
Board
(
page 8-106).
Replace the
OPFPLG
Harness
(
page 8-29).
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
