Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-107
Service Parts Disassembly
Replacement Note
Connectors P20, P21, and P30 on the Engine Control Board are not
used. Also, in the 6360 model, connector P21 has been removed
from the board as shown above.
s6360-219
P/J24
P30
P20
P/J18
P/J19
Hooks
