Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-21
Parts List
Parts List 5.2 Chute Assembly In - Service Parts List
ID No Part Number Name/Description
1. 116-1989-00
054K33370
Chute Assy In (with 2~30), (6300/6350)
Chute Assy In (with 2~31), (6360)
2. 011E16891 Fuser Lock Lever
3. Part of Spring Kit Spring Lever
4. Shaft Latch
5. Chute FSR In
6. 107E24210 Diode F
7. Part of Spring Kit Spring Diode F
8. Roll Pinch Dup
9. Spring Pinch Dup
10. Chute Dup In
11. Latch L
12. Part of Spring Kit Spring Latch
13. Spring BTR L
14. - -
15. Spring Pinch T
16. Roll Pinch Turn
17. Chute Turn In
18. Part of Spring Kit Spring ADC
19. 019K07146 CDT (ADC) Sensor Holder Assy (includes sensor)
20. 130E87512 Toner Full Sensor
21. - -
22. Part of Spring Kit Spring Bias DTC
23. Spring BTR R
24. Stopper BTR R
25. 116-1993-00
007K94370
Fuser Drive Assembly (with 26), (6300/6350)
Fuser Drive Assembly (with 26), (6360)
26. Wire Assy FSR Earth
27. Latch R
28. Part of Wiring
Harness Kit
Harness Assy FSR/ADC (J36-J136,J162,J361)
29. - -
30. Part of Wiring
Harness Kit
Harness Assy TNRFULL/FSR (J52-J142,J521)
31. Clamp
