Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-23
Parts List
Parts List 5.3 Chute Assembly Out - Service Parts List
ID No. Part Number Name/Description
1. 116-1994-00
054K33312
Chute Assy Out (With 2~35,PL5.4), (6300/6350)
Chute Assy Out (With 2~38,PL5.4, PL10.1.9), (6360)
2. Plate Latch
3. Spring Latch
4. Part of Spring Kit Spring Bias IDT1-l
5. Latch MPT
6. 116-1995-00
103K81310
Resistor Gs1 50m, (6300/6350)
Resistor Dup Out, (6360)
7. Gear MPT
8. Part of Spring Kit Spring Feed MPT
9. 121E92901 Feed Solenoid MPT
10. Arm MPT
11. Part of Spring Kit Spring N/F MPT
12. Follower R
13. Follower L
14. 130E87090 Sensor Photo No Paper (MPT)
15. Part of Actuator
Kit
Actuator No Paper MPT
16. Bearing
17. Cam MPT
18. Shaft MPT
19. Roll Core MPT
20. 059K36730 Feed Roller Assy MPT
21. Bearing Earth
22. - -
23. - -
24. - -
25. - -
26. Holder MPT L
27. 962K28260 Harness Assy Control Panel (OPEPANE2) (J22-J220)
28. Part of Wiring
Harness Kit
Harness Assy FRONT/DUP (J13-
P132,J133,J134,J135,P501) )
29. Wire Assy Dup Earth (J1321-J1322)
30. 802E51351 Lower Cover
31. 127E83860 Fuser Fan
32. 054E26831 Feed Chute
33. Part of Spring Kit Spring Earth Out2
34. Part of Spring Kit Spring No Paper MPT
35. 015K67343 Assy, Plate Bottom
36. Roll Actuator No Paper
37. Pin MSI
38. 059K45860 Roll Assy Env (6360)
