Xerox Phaser 6360 Service Manual

A-16 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Reference
Developer Motor High Speed
Normal Speed
Half Speed
Slow Speed
Reverse High Speed
Reverse Normal Speed
Reverse Half Speed
Reverse Slow Speed
Audible verification of motor
function.
CAUTION: Only run the developer motor
test once per power cycle to
avoid excessive amounts of
toner being forced inside the
developer.
HCF/LTA
Motor 1
High Speed
Normal Speed
Half Speed
Slow Speed
High Speed Continuous
Normal Speed Continuous
Half Speed Continuous
Slow Speed Continuous
Double High Speed
Double Normal Speed
Double Half Speed
Double Slow Speed
Double High Speed Continuous
Double Normal Speed Continuous
Double Half Speed Continuous
Double Slow Speed Continuous
Audible verification of motor
function.
HCF/LTA
Motor 2
High Speed
Normal Speed
Half Speed
Slow Speed
High Speed Continuous
Normal Speed Continuous
Half Speed Continuous
Slow Speed Continuous
Double High Speed
Double Normal Speed
Double Half Speed
Double Slow Speed
Double High Speed Continuous
Double Normal Speed Continuous
Double Half Speed Continuous
Double Slow Speed Continuous
Audible verification of motor
function.
Toner Motor Yellow
Toner Motor Magenta
Toner Motor Cyan
Toner Motor Black
Normal Speed Audible verification of motor
functionality.
CAUTION: Run the test just long enough
to verify operation (<5 sec.)
except when priming Auger
Tubes.
Rear Fan High Speed
Low Speed
High Speed Continuous
Low Speed Continuous
Audible verification of motor
function.
Check for airflow.
Service Diagnostics Tests and Utilities (Continued)
Test Control Panel Display and Test Definition

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
