Phaser 6300/6350/6360 Color Laser Printer Service Manual A-17
Reference
LVPS Fan High Speed
High Speed Continuous
Audible verification of motor
function.
Check for airflow.
Fuser Fan High Speed
Low Speed
High Speed Continuous
Low Speed Continuous
Audible verification of motor
functionality.
Check for airflow.
Sensor/Switch Tests - Tests the functionality of the sensors and switches.
Interlock Switch Sensor is On
Sensor is Off
Door A or B is open
Door A or B is closed
Registration Sensor Sensor is Off
Sensor is On
This test continuously cycles paper.
The sensor state changes as paper
passes the sensor.
NOTE This test can also be used as a
paper path transport test when
troubleshooting Jam conditions.
Exit Sensor Sensor is Off
Sensor is On
Move the Exit Actuator (PL5.1.2) to
toggle the sensor state.
Duplex Sensor Sensor is Off
Sensor is On
Move the Duplex Jam Actuator
(PL5.4.13) to toggle the sensor.
Full Stack Sensor Sensor is Off
Sensor is On
Move the Full Stack Actuator
(PL5.4.2) to toggle the sensor.
[Y][M][C][K] Toner
Low
Toner is Low
Toner is NOT Low
Displays current state of the sensor.
[Y][M][C][K] Toner
Cartridge Present
Sensor is Off
Sensor is On
Move the Toner Cartridge In switch
(PL7.2.7) to change the sensor.
Toner Cartridge is LOCKED.
Toner Cartridge is UNLOCKED.
[Y][M][C][K] CRUM
Sensor
Sensor is Off
Sensor is On
Move the Toner Cartridge In switch
(PL7.2.7) to change the sensor.
Toner Cartridge is LOCKED.
Toner Cartridge is UNLOCKED.
Tray [2] [3] [4] [5]
Low Paper Sensor
Size: XXXX
Paper is Not Low
Paper is Low
Move the Tray Rear Guide or
maunally toggle the Paper Size
Switch Acutators to the desired paper
size and verify the sensor output.
Fill tray with paper to the fill line.
Insert one sheet of paper in tray to
change the sensor.
Tray 1 (MPT) No
Paper Sensor
Paper is Not Present
Paper is Present
Move the Tray 1 No Paper Actuator
(PL5.3.15) to change sensor state.
Tray [2] [3] [4] [5] No
Paper Sensor
Paper is Not Present
Paper is Present
Insert Tray [2] [3] [4] [5] with an
adequate amount of paper.
Toggle the No Paper Actuator.
Service Diagnostics Tests and Utilities (Continued)
Test Control Panel Display and Test Definition
