Xerox Phaser 6360 Service Manual

A-18 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Reference
Transfer Roller Toner
Full Sensor
Toner Waste [Not] Full Block the Toner Full Sensor
(PL5.2.20) to change the sensor
state.
Image Unit Not
Installed Sensor
Image Unit is [Not] Present Open Door C to change the state of
the Switch.
Fuser Fan Rotation
Signal
Fuser Fan Rotation Sensor is:
OK
Failure
Status only
Rear Fan Rotation
Signal
Rear Fan Rotation Sensor is:
OK
Failure
Status only
LVPS Fan Rotation
Signal
Rear Fan Rotation Sensor is:
OK
Failure
Status only
CTD (ADC) Sensor Dark Value: #
Light Value: ###
Sensor OK
Status only
Remove the Transfer Roller to
observe change of state.
Fuser NC Sensor <Fuser NC Sensor>
Fuser (Not) Ready
Sensor (Failure) is OK
Remove Fuser to change sensor
state.
Fuser STS Sensor <Fuser STS Sensor>
Fuser (Not) Ready
Sensor (Failure) is OK
Remove Fuser to change sensor
state.
Fuser NC Sensor
Amplifier
<Fuser NC Sensor Amplifier>
Fuser (Not) Ready
Temperature Amplifier (Failure) is OK
Remove Fuser to change sensor
state.
Fuser Temp
Compensation
<Fuser Temp Compensation>
Fuser (Not) Ready
Compensation (Failure) is OK
Remove Fuser to change sensor
state.
Main Motor Rotation
Signal
Main Motor Rotation Sensor is:
OK
Failure
Status only
Developer Motor
Rotation Signal
Developer Motor Rotation Sensor is:
OK
Failure
Status only
Fuser Motor Rotation
Signal
Fuser Motor Rotation Sensor is:
OK
Failure
Status only
Clutch Tests - Tests the functionality of the clutches.
Registration Clutch
Tray 1 (MPT) Turn
Clutch (PL4.2.9)
Tray 3 Turn Clutch
Tray 4 Turn Clutch
Tray 5 Turn Clutch
Clutch is On
Clutch is Off
Audible verification of Clutch
functionality. You should hear a
continuous clicking until the test is
ended by pressing Cancel.
Service Diagnostics Tests and Utilities (Continued)
Test Control Panel Display and Test Definition

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
