Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual A-19
Reference
Solenoid Tests - Tests the functionality of the solenoids.
Tray [1 (MPT)][2][3]
[4][5] Feed Solenoid
Solenoid is On
Solenoid is Off
Audible verification of the Solenoid
function.
Maintenance - Cleans the Intermediate Transfer Unit within the Imaging Unit.
Clean Imaging Unit
IDT 1
Clean Imaging Unit
IDT 2
Printing..... Printing displays during the IDT
cleaning cycle.
The test continuously cycles paper
until Cancel is pressed.
NVRAM Access - This menu lets you read, set or reset the following values:
PostScript NVRAM
Reset
Resetting PostScript NVRAM...
Are you sure? Yes / NO
Restores the printer’s setup values to
their factory defaults.
MCU NVRAM Store/
Restore
Save Engine NVRAM
Restore Engine NVRAM
Saves printer installation date, printer
page count, imaging unit life count,
transfer roller life count to Image
Processor Board.
Restores previously saved data to the
Engine Control Board.
Toner Install Dates Black Toner Install Date
Cyan Toner Install Date
Magenta Toner Install Date
Yellow Toner Install Date
Allows toner cartridge install dates to
be viewed, or changed.
Toner CRUM Check (<Color> Not) Genuine Xerox Toner Verifies that genuine Xerox toner is
installed in the printer.
CRU Life Reset Resets life count of selected item.
Confirmed Reset or Unconfirmed Reset
Transfer Roller Life
Reset value: 0 Units: Pages
Black Developer (K) Life
Reset value: 0 Units: Revolutions
Cyan Developer (C) Life
Reset value: 0 Units: Revolutions
Magenta Developer (M) Life Reset
value: 0 Units: Revolutions
Yellow Developer (Y) Life
Reset value: 0 Units: Revolutions
Sets Transfer Roller life to unused
and resets the installation date to the
current date indicated by the printer.
NOTE Toner CRUM life counts cannot be
modified.
Resets component life count.
Service Diagnostics Tests and Utilities (Continued)
Test Control Panel Display and Test Definition

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
