Xerox Phaser 6360 Service Manual

A-20 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Reference
CRU Life Read Black Toner (K) Life
Range: 0-9001 Units: Auger turns
Cyan Toner (C) Life
Range: 0-9001 Units: Auger turns
Magenta Toner (M) Life
Range: 0-9001 Units: Auger turns
Yellow Toner (Y) Life
Range: 0-9001 Units: Auger turns
Transfer Roller Life
Range: 0-35100 Units: Pages
Read Printer Page Count
Imaging Unit
Count 1:Range: 0-38500 Units: Page
Count 2:Range: 0-257000 Units:
Rotations
Count 3:Range: 0-144189 Units: Total
Dispense Time
Count 4:Range: 0-560 Units: Toner
bottle exchange
Count 5:Range: 0-8492 Units: Total
Dispense Time relative to Count 4.
Fuser Life
Range value: 0-100000 Units: pages
Black Developer (K) Life
Range: 0-1608601 Units: Rotations
Cyan Developer (C) Life
Range: 0-1608601 Units: Rotations
Magenta Developer (M) Life
Range: 0-1608601 Units: Rotations
Yellow Developer (K) Life
Range: 0-1608601 Units: Rotations
Accesses the various life counts
stored in NVRAM.
Use the normal customer mode
features for resolving consumable life
issues rather than to rely upon this
test. This is due to special algorithms
used by the controller when
operating in customer mode as well
as past consumable state history that
is unavailable to diagnostics.
NOTE This test reads the current static
information from the engine. The
test does not access history that
may have been stored while
operating in customer mode.
IP Controller Diagnostics - Tests basic functionality of the Image Processor Board.
RAM Read/Write Test Executing.....
Passed
Does an extended memory test on
the Image Processor Board.
NOTE Cycle power to the printer after
executing this test.
Exit - Exits Service Diagnostics and reboots the printer.
Service Diagnostics Tests and Utilities (Continued)
Test Control Panel Display and Test Definition

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
